2015 HAAS VF2SS CNC Mill
Sold
2015 HAAS VF2SS CNC Mill
Description
Probe
Programmable Coolant
High Speed Machining
Upgraded Memory
Specifications
| Manufacturer | HAAS |
| Model | VF2SS CNC Mill |
| Year | 2015 |
| Condition | Used |
| X Axis Travel | 30" |
| Y Axis Travel | 16" |
| Z Axis Travel | 20" |
| Rapid Rate X Axis | 1,400 IPM |
| Rapid Rate Y Axis | 1,400 IPM |
| Rapid Rate Z Axis | 1,400 IPM |
| Table Size | 36" x 18" |
| Max Table Load | 1,500 LBS |
| Spindle Motor | 30 HP |
| Spindle Speed | 12,000 RPM |
| Spindle Taper | 40 CT |
| Tool Changer | 24 ATC |
| Max Cutting | 833 ipm |
| Max Weight | 1500 lbs |
| Max Thrust X | 1995 ibf |
| Max Thrust Y | 1995 ibf |
| Max Thrust Z | 3085 ibf |
| Chip-to-Chip | 3.6 s |
| Coolant Cap | 55 gal |
| Amps 3 Phase | 35A (High) |
| Dimensions | 106" x 101" x 101" |
| Weight | 7,800 lbs |
